MIL-D-89009
TABLE 42.
Format and content for Data Volume (DV) feature class
schema table.
{Header length};\
Data volume Feature Class Schema Table;-;\
ID=I,
1,N,Row Identifier,-,-,:\
FEATURE_CLASS=T, 8,P,Name of Feature Class,-,-,:\
TABLE1=T,
12,P,First Table,-,-,:\
FOREIGN_KEY=T,
16,P,Column Name in First Table,-,-,:\
TABLE2=T,
12,P,Second Table,-,-,:\
PRIMARY_KEY=T,
16,P,Column Name in Second Table,-,-,:;
1
DVAREA
DVAREA.AFT
ID
FAC
ID
2
DVAREA
FAC
ID
DVAREA.AFT
ID
TABLE 43.
Format content for Drainage (DN) feature class schema
table.
{Header length};\
Drainage Feature Class Schema Table;-;\
ID=I,
1,N,Row Identifier,-,-,:\
FEATURE_CLASS=T, 8,P,Name of Feature Class,-,-,:\
TABLE1=T,
12,P,First Table,-,-,:\
FOREIGN_KEY=T,
16,P,Column Name in First Table,-,-,:\
TABLE2=T,
12,P,Second Table,-,-,:\
PRIMARY_KEY=T,
16,P,Column Name in Second Table,-,-,:;
1
DNAREA
DNAREA.AFT
ID
FAC
ID
2
DNAREA
FAC
ID
DNAREA.AFT
ID
3
DNLINE
DNLINE.LFT
ID
EDG
ID
4
DNLINE
EDG
ID
DNLINE.LFT
ID
TABLE 44.
Format and content for Geographic Regions (GR)
feature class schema table.
{Header length};\
Geographic Regions Feature Class Schema Table;-;\
ID=I,
1,N,Row Identifier,-,-,:\
FEATURE_CLASS=T, 8,P,Name of Feature Class,-,-,:\
TABLE1=T,
12,P,First Table,-,-,:\
FOREIGN_KEY=T,
16,P,Column Name in First Table,-,-,:\
TABLE2=T,
12,P,Second Table,-,-,:\
PRIMARY_KEY=T,
16,P,Column Name in Second Table,-,-,:;
1
GRAREA
GRAREA.AFT
ID
FAC
ID
2
GRAREA
FAC
ID
GRAREA.AFT
ID
3
GRLINE
GRLINE.LFT
ID
EDG
ID
4
GRLINE
EDG
ID
GRLINE.LFT
ID
5
GRTEXT
GRTEXT.TFT
ID
TXT
ID
6
GRTEXT
TXT
ID
GRTEXT.TFT
ID
44
