MIL-D-89009
TABLE 29.
Content and format for Roads (RD) feature class
schema table.
{Header length};\
Roads Feature Class Schema Table;-;\
ID=I,
1,N,Row Identifier,-,-,:\
FEATURE_CLASS=T, 8,P,Name of Feature Class,-,-,:\
TABLE1=T,
12,P,First Table,-,-,:\
FOREIGN_KEY=T,
16,P,Column Name in First Table,-,-,:\
TABLE2=T,
12,P,Second Table,-,-,:\
PRIMARY_KEY=T,
16,P,Column Name in Second Table,-,-,:;
1
RDLINE
RDLINE.LFT
EDG_ID
EDG
ID
2
RDLINE
EDG
RDLINE.LFT_ID
RDLINE.LFT
ID
3
RDTEXT
RDTEXT.TFT
TXT_ID
TXT
ID
4
RDTEXT
TXT
RDTEXT.TFT_ID
RDTEXT.TFT
ID
TABLE 30.
Content and format for Transportation Structure (TS)
feature class schema table.
{Header length};\
Transportation Structure Feature Class Schema Table;-;\
ID=I,
1,N,Row Identifier,-,-,:\
FEATURE_CLASS=T, 8,P,Name of Feature Class,-,-,:\
TABLE1=T,
12,P,First Table,-,-,:\
FOREIGN_KEY=T,
16,P,Column Name in First Table,-,-,:\
TABLE2=T,
12,P,Second Table,-,-,:\
PRIMARY_KEY=T,
16,P,Column Name in Second Table,-,-,:;
1
TSLINE
TSLINE.LFT
EDG_ID
EDG
ID
2
TSLINE
EDG
TSLINE.LFT_ID
TSLINE.LFT
ID
3
TSPOINT
TSPOINT.PFT
END_ID
END
ID
4
TSPOINT
END
TSPOINT.PFT_ID
TSPOINT.PFT
ID
5
TSTEXT
TSTEXT.TFT
TXT_ID
TXT
ID
6
TSTEXT
TXT
TSTEXT.TFT_ID
TSTEXT.TFT
ID
