MIL-D-89009
TABLE 14. DCW thematic layers, coverages, and feature classes.
DCW thematic library
Coverage
Feature classes
layers
name
Area
Line
Point
Text
Aeronautical
AE
AEPOINT
Cultural Landmarks
CL
CLAREA
CLLINE
CLPOINT
CLTEXT
Data Quality
DQ
DQAREA
DQLINE
DQTEXT
Drainage
DN
DNAREA
DNLINE
DNPOINT
DNTEXT
Drainage-Supplemental
DS
DSPOINT
Hypsography
HY
HYAREA
HYLINE
HYPOINT
Hypsography-Supplemental
HS
HSLINE
HSPOINT
Land Cover
LC
LCAREA
LCPOINT
LCTEXT
Ocean Features
OF
OFLINE
OFPOINT
OFTEXT
Physiography
PH
PHLINE
PHTEXT
Political/Oceans
PO
POAREA
POLINE
POPOINT
POTEXT
Populated Places
PP
PPAREA
PPPOINT
PPTEXT
Railroads
RR
RRLINE
RRTEXT
Roads
RD
RDLINE
RDTEXT
Transportation Structure
TS
TSLINE
TSPOINT
TSTEXT
Utilities
UT
UTLINE
UTTEXT
Vegetation1
VG
VGAREA
1 Vegetation data is only available on Disc 1 for the continental U.S.
TABLE 15. Additional coverages in each DCW library.
Additional DCW library
Coverage
Feature class
coverages
codes
Area
Line
Point
Text
Gazetteer
GAZETTE
GAZETTE
Library Reference
LIBREF
LIBREF
Tile Reference
TILEREF
TILEREF
TABLE 16.
Content and format for Aeronautical (AE) feature
class schema table.
{Header length};\
Aeronautical Feature Class Schema Table;-;\
ID=I,
1,N,Row Identifier,-,-,:\
FEATURE_CLASS=T, 8,P,Name of Feature Class,-,-,:\
TABLE1=T,
12,P,First Table,-,-,:\
FOREIGN_KEY=T,
16,P,Column Name in First Table,-,-,:\
TABLE2=T,
12,P,Second Table,-,-,:\
PRIMARY_KEY=T,
16,P,Column Name in Second Table,-,-,:;
1
AEPOINT
AEPOINT.PFT
END_ID
END
ID
2
AEPOINT
END
AEPOINT.PFT_ID AEPOINT.PFT
ID
28
