MIL-D-89009
TABLE 11.
Format and content for BROWSE library Geographic
Reference Table (GRT).
{Header length};\
Geographic Reference Table;-;\
ID=I,
1,P,Row Identifier,-,-,:\
DATA_TYPE=T,
3,N,Data Type,-,-,:\
UNITS=T,
3,N,Units,-,-,:\
ELLIPSOID=T,
15,N,Ellipsoid,-,-,:\
ELLIPSOID_DETAIL=T, 50,N,Ellipsoid Details,-,-,:\
VERT_DATUM_REF=T,
15,N,Datum Vertical Reference,-,-,:\
VERT_DATUM_CODE=T,
3,N,Vertical Datum Code,-,-,:\
SOUND_DATUM=T,
15,N,Sounding Datum,-,-,:\
SOUND_DATUM_CODE=T,
3,N,Vertical Datum Code,-,-,:\
GEO_DATUM_NAME=T,
15,N,Datum Geodetic Name,-,-,:\
GEO_DATUM_CODE=T,
3,N,Datum Geodetic Code,-,-,:\
PROJECTION_NAME=T,
20,N,Projection Name,-,-,:;
1\
GEO\
014\
WGS 84\
A=6378137 B=6356752 Meters\
MEAN SEA LEVEL\
015\
MEAN SEA LEVEL\
015\
WGS 84\
WGE\
ROBINSON
TABLE 12.
Format and content for BROWSE Coverage Attribute Table
(CAT).
{Header length};\
Coverage Attribute Table;-;\
ID=I,
1,N,Row Identifier,-,-,:\
COVERAGE_NAME=T, 8,P,Coverage name,-,-,:\
DESCRIPTION=T,
50,N,Coverage description,-,-,:\
LEVEL=I,
1,N,Topology level,-,-,:;
1
CO
ONC COMPILATION DATE
3
2
DV
DATA VOLUME
3
3
DN
DRAINAGE
3
4
GR
GEOGRAPHIC REGIONS
3
5
DA
HYPSOGRAPHIC DATA AVAILABILITY
3
6
IN
ONC INDEX
3
7
PO
POLITICAL/OCEANS
3
8
PP
POPULATED PLACES
0
24
