MIL-D-89009
TABLE 55.
Format and example of content for Face (FAC) table.
{Header length};\
Face Primitives;-;\
ID=I,
1,P,Row Identifier,-,-,:\
*.AFT_ID=I,
1,F,Foreign Key to Area Feature Table,-,-,:\
RING_PTR=I,
1,F,Foreign Key to Ring Table,-,-,:;
1
1
12
2
2
13
3
3
14
:
:
:
n
n
n
NOTE: The "*" preceding the ".AFT_ID" is replaced with the appropriate
feature class name.
TABLE 56.
Format and example of content for Face Bounding
Rectangle (FBR) table.
{Header length};\
Face Bounding Rectangle Table;-;\
ID=I,
1,P,Row Identifier,-,-,:\
XMIN=F,
1,N,Minimum X Coordinate,-,-,:\
YMIN=F,
1,N,Minimum Y Coordinate,-,-,:\
XMAX=F,
1,N,Maximum X Coordinate,-,-,:\
YMAX=F,
1,N,Maximum Y Coordinate,-,-,:;
1
-76.333359
36.916660
-76.250031
36.999981
2
-76.333359
36.999451
-76.331215
36.999981
3
-76.333359
36.994431
-76.321991
36.999981
:
:
:
:
:
n
n
n
n
n
i. Ring primitive. The ring table is topologically linked
to the face table and edge table within a coverage.
j. Ring table. The ring table contains a ring row
identifier column, face column, and edge column. The
first entry in the ring table for a particular face
contains the outer ring of that face. Subsequent rings
for the same face indicate internal rings within the
outer ring. The format and an example of the content
for a ring primitive table are shown in TABLE 57.
52
