MIL-D-89009
APPENDIX
TABLE 63.
Culture landmarks integer value description table
(INT.VDT).
{Header length};\
Culture landmarks Integer Value Description Table;-;\
ID=
I, 1,N,Row Identifier,-,-,:\
TABLE=
T,12,P,Name of Feature Table,-,-,:\
ATTRIBUTE= T,16,P,Attribute Name,-,-,:\
VALUE=
I, 1,P,Attribute Value,-,-,:\
DESCRIPTION=T,50,N,Attribute Value Description,-,-,:;
1
CLTEXT.TFT
LEVEL
1
Unattached Cultural annotation
2
CLTEXT.TFT
SYMBOL
1
Black annotation
TABLE 64. Culture landmarks area feature table (CLAREA.AFT)1
{Header length};\
Culture Landmark Areas;CLAREA.DOC;\
ID=
I, 1,P,Row Identifier,-,-,:\
CLPYLABEL=T,50,N,Landmark label,-,-,:\
TILE_ID= S, 1,F,Tile Reference Identifier,-,CLAREA.ATI,:\
FAC_ID=
I, 1,F,Face Primitive Foreign Key,-,-,:;
1
Filtration Beds
421
1
2
Tank Farm
465
2
:
:
:
:
n
n
n
n
CLPYLABEL
The type of landmark is entered in this field as a text string.
Landmarks with labels require the label to be entered in this field.
Representative values are:
ONC Codes
Forts
908.2
Athletic fields
908.8
Area delimiting lines
908.12
Structure other than buildings
908.19
1This
table does not appear in the Eurnasia Library.
86
